Rockfon® Mono Acoustic

Perfect for ceilings and walls, the innovative monolithic surface delivers outstanding acoustic comfort and fire protection
Order Sample
Download Datasheet
Download Datasheet
Back
Flat or curved. Direct or suspended installation. The perfect design solution for new-build or renovation projects alike
The refined white surface provides high light reflection and light diffusion, ensuring even light distribution and reducing the need for artificial light
Available in custom colours or 33 colours from the Rockfon Colours of Wellbeing range
A completely seamless system that allows for easy integration of all services and the possibility for surface maintenance
Monolithic system comprising of a stone wool panel, filler and render
Visible side: acoustic render
Rear side: high performance membrane (Rockfon Mono Acoustic Direct and Rockfon Mono Acoustic Flecto are supplied with a mineral fleece)

Colour

Colour group

All
All
Greys & Blacks
Yellows
Browns & Beige
Blues
Reds & Pinks
Greens
Whites

White - Elegant render

ColourWhite - Elegant render
Colour groupWhites
Light reflection87

Order Sample

Quantity:
1

Edge

Select an edge
Select an edge
FE
White - Elegant render

Stone wool tile

White - Elegant render

87 % Light reflection

More Info

Order Sample

Quantity:
1

Edge

Select an edge
Select an edge
FE
White - Elegant render
01
Stone
02
Plaster
03
Gravel
05
Zinc
06
Concrete
08
Anthracite
09
Charcoal
10
Moon
12
Mint
13
Sandalwood
17
Mastic
18
Iron
20
Stucco
21
Chalk
22
Linen
23
Hemp
24
Cork
25
Earth
26
Clay
28
Ebony
30
Sand
31
Sage
32
Eucalyptus
34
Seaweed
42
Fresh
47
Azure
48
Storm
49
Space
51
Mustard
71
Scarlet
74
Petal
75
Seashell
76
Coral

Case studies featuring Rockfon® Mono Acoustic

1/259

Recommended application areas

Office

Meeting Room
Open Plan Office
Reception
Canteen
Corridor

Education

Auditorium
Library
Corridor
Canteen

Retail

Boutiques
Convention Centre
Department Store
Shopping Centre
Showroom

Leisure

Auditorium / Concert Hall
Museum
Restaurant / Pub / Nightclub
Hotel
Restaurant

Back

Sound absorption details

Practical Sound Absorption Coefficient (αp)
Edge Thickness Suspension height 125Hz 250Hz 500Hz 1000Hz 2000Hz 4000Hz Sound absorption class αw NRC
FE 40mm 200mm 0.45 0.65 0.85 0.90 1.00 1.00 A 0.90 0.80
FE Direct 25mm 25mm 0.10 0.40 0.85 0.95 1.00 1.00 C 0.70 0.80
FE Direct 40mm 40mm 0.25 0.80 0.95 0.95 1.00 1.00 A 1.00 0.95

Sound absorption is measured in accordance with ISO 354.

Sound absorption data αp, αw and absorption class are calculated in accordance with ISO 11654. Sound absorption properties of islands and baffles are quantified by the equivalent sound absorption area Aeq expressed as m² per item.

Back
Sound curve
Back
Sound curve
Back
Sound curve

Other performances

Reaction To Fire Reaction To Fire A2-s1,d0, B-s1,d0 (Colour)
Reaction to fire is classified in accordance with EN 13501-1.
Fire Resistance Fire Resistance Rockfon Mono Acoustic achieves up to 60 min. in accordance with European test standards and national approvals.
Please contact Rockfon for fire resistance documentation.
The stone wool core of ROCKFON products is non-combustible with a melting point of more than 1000°C and provides fire protection. Some ROCKFON ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms.
Light reflection and light diffusion Light reflection and light diffusion 87% light reflection (White) >99% light diffusion (White) Colour-dependent (Colour)
Light reflection expressed in % is measured in accordance with ISO 7724-2.
Visual Appearance Visual Appearance L value: 94.5 (White)
The whiteness (L value) of the product is tested in accordance with ISO 7724 and measured on a scale from 1 (black) to 100 (white).
Humidity And Sag Resistance Humidity And Sag Resistance Up to 100% RH.
No visible deflection in high humidity
ROCKFON ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 0°C to 40°C. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimises the final weight of the fully-installed ceiling. ROCKFON ceiling tiles are predominantly classified as Class 1/C/0N in accordance with EN 13964. Certain module sizes (width above 700mm) are Class 2/C/0N.
Cleaning Cleaning Vacuum
Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
Hygiene Hygiene Stone wool provides no sustenance to microorganisms
Stone wool provides no sustenance to the following microorganisms tested in accordance with JIS Z 2801:2000 and ASTM C 1338-96: – Escherichia coli – Staphylococcus aureus – Methicillin-resistant staphylococcus aureus (MRSA) – Stachybotrys chartarum – Penicillium brevicumpactum – Alternaria tenuissima – Aspergillus niger – Sporobolomyces roseum – Rhodotorula rubra
Environment Environment Fully recyclable stone wool
Indoor Environment Indoor Environment A selection of Rockfon products have been awarded the Finnish M1 emission classification for building materials and the Danish Indoor Climate Label for low emission products
Back
Reaction to fire is classified in accordance with EN 13501-1.
Back
The stone wool core of ROCKFON products is non-combustible with a melting point of more than 1000°C and provides fire protection. Some ROCKFON ceilings have been tested and classified in accordance with European norm EN 13501-2 and/or national norms.
Back
Light reflection expressed in % is measured in accordance with ISO 7724-2.
Back
The whiteness (L value) of the product is tested in accordance with ISO 7724 and measured on a scale from 1 (black) to 100 (white).
Back
ROCKFON ceiling tiles are dimensionally stable even at humidity levels of up to 100% relative humidity and can be installed at all temperatures ranging from 0°C to 40°C. They can be installed during the very early stage of the build (when windows are not fully sealed). Their lightweight yet stable non-hygroscopic character minimises the final weight of the fully-installed ceiling. ROCKFON ceiling tiles are predominantly classified as Class 1/C/0N in accordance with EN 13964. Certain module sizes (width above 700mm) are Class 2/C/0N.
Back
Vacuum: The surface can be vacuum cleaned with a soft brush attachment.
Back
Stone wool provides no sustenance to the following microorganisms tested in accordance with JIS Z 2801:2000 and ASTM C 1338-96: – Escherichia coli – Staphylococcus aureus – Methicillin-resistant staphylococcus aureus (MRSA) – Stachybotrys chartarum – Penicillium brevicumpactum – Alternaria tenuissima – Aspergillus niger – Sporobolomyces roseum – Rhodotorula rubra
Back
Back
Back

Full range

Edge Dimensions (mm) Thickness (mm) Weight (Kg/m2) Min. suspension height (mm) Recommended installation system
FE 1200 x 1200 40 6.00 90

Sound absorption details

αw 0.90
NRC 0.80
Sound absorption class A

Tile details

Minimum installation height 90 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE 1800 x 1200 40 6.00 90

Sound absorption details

αw 0.90
NRC 0.80
Sound absorption class A

Tile details

Minimum installation height 90 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Direct 1200 x 1200 25 4.00 25

Sound absorption details

αw 0.70
NRC 0.80
Sound absorption class C

Tile details

Minimum installation height 25 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Direct 1200 x 1200 40 6.00 40

Sound absorption details

αw 1.00
NRC 0.95
Sound absorption class A

Tile details

Minimum installation height 40 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Direct 1200 x 900 25 4.00 25

Sound absorption details

αw 0.70
NRC 0.80
Sound absorption class C

Tile details

Minimum installation height 25 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Direct 1200 x 900 40 6.00 40

Sound absorption details

αw 1.00
NRC 0.95
Sound absorption class A

Tile details

Minimum installation height 40 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Direct 1800 x 1200 40 6.00 40

Sound absorption details

αw 1.00
NRC 0.95
Sound absorption class A

Tile details

Minimum installation height 40 mm

Packaging

Pieces Per Pack
Area Per Pack m2
FE Flecto 1200 x 900 40 6.00 40

Tile details

Minimum installation height 40 mm

Packaging

Pieces Per Pack
Area Per Pack m2

*MS - minimum suspension incl. panel thickness
For this product, module size = exact dimension. Panel weight is stated exclusive of filler and render.
Do not install Rockfon Mono Acoustic where a pressure difference can be created between the front and rearside of a Rockfon Mono Acoustic ceiling.
Rockfon Mono Acoustic Direct and Rockfon Mono Acoustic Flecto can only be installed directly onto an airtight surface.
